リープヘル MK 140
税別価格
金額応相談
4
お気に入り
シェア
検索結果を保存印刷
情報
機械カテゴリー
オールテレーンクレーン
メーカー／型式
リープヘル MK 140
製造年
2021
稼働時間・走行距離
6357 km
国
ドイツ
マスカス ID
97A2DF32
詳細
ストック番号
ZG21502
総重量
60000 kg
オリジナルカラー
Gelb
その他情報
1 pc. Grid tip: extensions for luffing mode to 62.5 m and 65 m
1 pc. Ballasting: Ballasting package consisting of self-ballasting device and self-ballasting additional ballast 9t (2x 3 t, 2x 1.5 t)
Basic version
Basic version
radius 58.5 m
hook height of horizontal boom 39.9 m
Consisting of crane chassis: Liebherr 5-axle front link chassis Front manoeuvring coupling, tool kit, storage compartment for support plates
Traction engine: Liebherr in-line 6-cylinder diesel engine, output 400 kw (544 hp), exhaust system with integrated spark arrester, exhaust emissions in accordance with Regulation (EU) 2016/1628 and EPA/CARB
Transmission: ZF TraXon automated manual transmission with Intarder, 12 forward and 2 reverse gears, two-stage transfer case
Axles: 10 x 6 drive, axles 2, 4 and 5 driven, levelling suspension, suspension travel -100/ + 100 mm
Hydraulic stabilisers: Operation via portable control panel with Bluetooth (BTT); automatic levelling; electronic inclination display; support pressure display; automatic detection of support width
Tyres: 10-ply; 385/95 R25 (14.00 R 25)
Steering: All axles steered
dual-circuit system; active rear-axle steering with 5 drive
programmes: 1. road drive
2. all-wheel steering
3. crab steering
4. reduced shearing
5. independent steering
Brake: Dual-circuit brake system with air disc brakes on all wheels
Cab: Heated exterior mirrors; electrically adjustable main mirror; electric windows; air-conditioned driver's seat; pneumatically sprung driver's seat with lumbar support and seat heating; steering wheel infinitely adjustable in height and angle; air conditioning; Bluetooth radio; rear view camera system with colour monitor; 12 V socket; auxiliary heating independent of engine incl. timer; 6 kg fire extinguisher
Electrical system: 24 V direct current; 2 batteries, 170 Ah each, 4 rotating beacons (yellow); support lighting; 1 socket at the rear of the vehicle (15-pin
24 V); external power connection for crane supply; 400 V / 50 Hz; electrical distributor 1 x 32 A CEE; 2 x 16 A CEE; 3x shockproof socket with RCD for external consumer connection, battery charger for charging the chassis battery during genset and mains operation, acoustic reversing alarm
Turntable: Liebherr ball bearing slewing ring with central lubrication system; current collector to the vehicle chassis
Tower: Telescopic tower in solid-wall design; 2-way telescopic; 2 standard intermediate hook heights 20.8m and 30.3m
Boom: 4-part boom in lattice construction; hydraulic boom slewing device; various boom air assembly curves; 15°/30°/45° boom pitch; adjustable boom mode for luffing from -20° to 70° under load; equipment for site lighting with 6x LED spotlights on the tower and in the boom; plug-in flight warning system & switchable flashing light or continuous light
Drives: hoist gear; trolley travelling gear; stepless tensioning winch and slewing gear with frequency converter; noise protection cladding on the winch gear
Crane control: Programmable logic controller (PLC); ABB working range limitation; load sway damping and wind load control; anemometer; radio window control with display
Lift cab: Infinitely height-adjustable with own drive as crane operator lift; crane operator's chair with seat heating and seat contact switch; with integrated master switches; Bluetooth radio; air conditioning; external intercom with microphone; rescue device for emergency exit; electronic monitoring system (EMS) with inclination monitoring and support pressure display
Diesel generator: 48.0 kVA
Trolley: Standard trolley
Load increase: Load package
load increase with additional LM3 load curve. The drives are driven more slowly. Superimposed ...
Scheckheftgepflegt, HU neu, Vermietung möglich
もっと表示する
