コベルコ建機 SK 60

# KOBELCO SK60 Crawler Excavator Specifications Model: KOBELCO SK60 Operating Weight: 5950 kg Bucket Capacity: 0.24 m³ Transport Dimensions (L×W×H): 5850 × 1960 × 2550 mm Track Shoe Width: 400 mm Travel Speed (High/Low): 3.9 / 2.2 km/h Swing Speed: 10 rpm Bucket Digging Force: 40.1 kN Arm Digging Force: 25.2 kN Max Digging Depth: 3792 mm Max Digging Radius: 6114 mm Max Dumping Height: 3960 mm Max Digging Height: 5730 mm Ground Clearance: 335 mm ## Engine Engine Model: Yanmar 4TNV94L Rated Net Power: 42.4 kW / 2200 rpm Displacement: 3054 cc Cylinders: 4 in-line Fuel Tank Capacity: 100 L ## Hydraulic System Hydraulic Type: Load sensing hydraulic system Main Pump Max Flow: 114 L/min Max Working Pressure: 24.5 MPa
